ASUS PRIME X299 EDITION 30 ATX Motherboard – 3-Year Warranty

Description

Intel ATX motherboard LGA 2066 for Intel Core X-series processors with AI Overclocking, 16 IR3555 power stages, DDR4 4266 MHz, Wi-Fi 6, 5 Gbps Ethernet, Type-C Thunderbolt 3 ports, Triple M.2, USB 3.2 front panel connector and Aura Sync RGB lighting

• CPUIntel Socket 2066 Core X-Series Processors
  Optimized for Intel Core X-Series 10000 Processor Family
  * The Intel Turbo Boost Max Technology 3.0 support depends on the CPU types
  * Refer to www.asus.com for CPU support list
• ChipsetIntel X299
• Memory(Intel Core i9 10000 X-Series CPU)
  8 x DIMM, Max. 256GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3600(O.C.)/3400(O.C.)/3333(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  (Intel Core i9 9000/7000 and i7 9000 X-Series CPU)
  8 x DIMM, Max. 256GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3600(O.C.)/3400(O.C.)/3333(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  Supports Intel Extreme Memory Profile (XMP)
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer towww.asus.comfor the Memory QVL (Qualified Vendors Lists).
• Thunderbolt2 x Intel Thunderbolt 3 ports(TypeC) support DisplayPort and Thunderbolt video outputs
  Supports DisplayPort 1.4/ with max. resolution 7680/ x 3840/@ 60 Hz*
  * VGA resolution support depends on VGA cards’ resolution.
  Data transfer rate up to 40 Gbps
  Daisy-chain up to 12 Thunderbolt devices
  Up to 5V/3A, 15W charging support
• Multi-GPU SupportSupports NVIDIA Quad-GPU SLI Technology
  Supports NVIDIA 3-Way SLI Technology
  Supports NVIDIA 2-Way SLI Technology
  Supports AMD Quad-GPU CrossFireX Technology
  Supports AMD 3-Way CrossFireX Technology
• Expansion Slots48-Lane CPU-
  3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
  2 x PCIe 3.0/2.0 x1 *¹
  44-Lane CPU-
  3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
  2 x PCIe 3.0/2.0 x1 *¹
  28-Lane CPU-
  2 x PCIe 3.0/2.0 x16 (x16, x16/x8) *²
  2 x PCIe 3.0/2.0 x1 *¹
• StorageIntel X299 Chipset :
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*³
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*⁴
  8 x SATA 6Gb/s port(s)*⁵
  Support Raid 0, 1, 5, 10
  Intel Rapid Storage Technology supports
  (Intel Core i9 10000 X-Series CPU) :
  2 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*⁴
  Support Raid 0, 1, 5, 10
  Intel Virtual RAID on CPU(VROC)
  (Intel Core i9 9000/7000 and i7 9000 X-Series CPU) :
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*⁴
  Support Raid 0, 1, 5, 10
  Intel Virtual RAID on CPU(VROC)
  Intel Optane Memory Ready *⁶
• LANAquantia AQC111C 5G LAN
  Intel I219V, 1 x Gigabit LAN
  ASUS Turbo LAN Utility
  ASUS LAN Guard
• Wireless Data NetworkIntel Wi-Fi 6 AX200
  Wi-Fi 802.11 ax, Bluetooth 5.0
  Supports channel bandwidth: HT20/HT40/HT80/HT160
  2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)withMU-MIMO supportsdualfrequency band 2.4/5GHz
  Up to 2.4Gbps transfer speed
• BluetoothBluetooth 5.0
• AudioRealtek S1220A 8-Channel High Definition Audio CODEC
  – Power pre-regulator reduces power input noise to ensure consistent performance
  – Impedance sense for front and rear headphone outputs
  – Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  Audio Feature :
